DM-16/11 Plaster sprayer

Uses

  • Plasters for indoors and outdoors
  • Calcium and gypsum-based plasters
  • Thermal insulation glue
  • Thermal plasters
  • Thermal insulation
  • Self-leveling floor screeds
  • Paste products spraying
  • Joints filling
  • Description

    Its compact design and small size make DM-16/11 handy to move and allow operator to work easily in any construction site.
    Ideal to work with pre-mixed plasters, thermal insulation glues and finishing plasters.
    It is available single-phase 230V 2,2kW and three-phase 400V 5,5kW. Single-phase version is equipped with advanced electric board and inverter.
    DM-16/11 is manufactured in strict compliance with all safety rules, with high quality components and completely galvanized.

    Size

    Loading height
    1000 mm
    Width
    710 mm
    Length
    1400 mm
    Weight
    170 kg

    Technical features

    Voltage
    230V 50/60Hz
    400V 50Hz
    Power
    2,2 kW
    5,5 kW
    Inverter
    yes
    No
    Flow rate
    5-16 l/min
    27 l/min
    Capacity
    80 l
    80 l
    Pumping distance
    max 25 m
    max 30 m
    Grain size
    3 mm
    3 mm
    * Orientative grain size, according to quality and material composition

    Standard equipment for pre-mixed plaster

    15-meter grout tube with air tube and control
    1 plaster gun
    Electric board with inverter
    Water unit with pump
    1 compressor
    Stator and rotor
    Supply envelope and keys
    Use and maintenance manual
    Declaration of conformity

    SET FOR THERMAL PLASTERS

    10-meter ø35 grout tube with air tube and control
    1 gun for Duse plaster ø16
    Stator and rotor
    Termomix

    SET FOR THERMAL INSULATION GLUE

    15-meter grout tube ø25 equipped with air tube and control
    1 gun for thermal insulation glue
    Spray head
    Stator and rotor
    Termomix

    Filling set

    10-meter grout tube ø25
    12-meter control button cable
    2 filling nozzles
    Stator and rotor

    floor Screed set

    10-meter grout tube ø35
    12-meter control button cable
    Stator flange
    Stator and rotor
    Water tank
    Hobnailed shoes
